Reynaers Master Patio
Reynaers' most complete lift-slide solution — a premium aluminum system pairing a 90% glass-to-frame ratio with the structural capacity for genuinely oversized, heavy panels.
Request a QuoteSpecifications
| System | Reynaers MasterPatio (Belgium) |
|---|---|
| Frame Material | Thermally broken aluminum |
| Glazing | Double or triple glazing up to 62mm |
| U-Factor | As low as 0.14 Btu/h·ft²·°F |
| Glass-to-Frame Ratio | Up to 90% visible glass |
| Max Size | Sash up to 11'10" tall × 9'10" wide; element height up to 12'2" (3.7m) |
| Weight Capacity | Up to 500kg motorized vent, 1200kg for fixed panes |
| Hardware | Fully concealed hardware; optional motorized operation |
| Security | PAS 24 and RC2 certified |
| Warranty | 10-year frame, 10-year glass |
Details
Master Patio is our top-tier aluminum lift-slide recommendation, built to pair with our MasterLine 8 windows for a single, consistent frame language across an entire glazed elevation. Concealed hardware and slim sightlines push the glass-to-frame ratio up to 90%, so the opening reads as almost entirely glass when closed.
The system is engineered for genuinely large formats — sashes up to 3.6m tall, elements up to 3.7m, and motorized operation for vents up to 500kg — while still holding U-factors as low as 0.14 Btu/h·ft²·°F and PAS 24 / RC2 security certification. It’s the door to spec when a project’s showpiece opening needs to be both oversized and effortless to operate.
